Venieri VF7.23B
Browse All Venieri or Loader Backhoe Models
Contents:
Backhoe
| Load Height - Std | 16.08 ft in (4900 mm) |
| Reach From Swivel - Std | 18.16 ft in (5535 mm) |
| Dig Depth - Std | 16.74 ft in (5100 mm) |
Dimensions
| Transport Length | 18.15 ft in (5530 mm) |
| Transport Width | 6.89 ft in (2100 mm) |
| Transport Height | 10.67 ft in (3250 mm) |
Loader
| Clearance At Max Dump Height | 11 ft in (3350 mm) |
| Bucket Width | 82.68 in (2100 mm) |
| Bucket Capacity | 1.12 yd3 (0.85 m3) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2351 |
| Engine Model | 1004-40T |
| Gross Power | 100.6 hp (75 kw) |
| Power Measured @ | 2200 rpm |
| Aspiration | Turbocharged |
| Displacement | 244.1 cu in (4 L) |
Operational
| Operating Weight 4wd | 15873.3 lb (7200 kg) |
| Turning Radius | 14 ft in (4250 mm) |
Transmission
| Transmission Type | Hydrostatic |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 18.7 mph (30 km/h) |
| Max Speed Reverse | 18.7 mph (30 km/h) |
Hydraulic
| Pump Type | Piston |
| Pump Flow Capacity | 29.4 gal/min (111 L/min) |
| Relief Valve Pressure | 3335.9 psi (23000 kPa) |
