Komatsu PC150LC-6
Browse All Komatsu or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 27.96 ft in (8520 mm) |
| Shipping Height Of Unit | 10.26 ft in (3125 mm) |
| Max Cutting Height | 28.79 ft in (8775 mm) |
| Max Loading Height | 20.12 ft in (6130 mm) |
| Max Reach Along Ground | 26.84 ft in (8180 mm) |
| Max Vertical Wall Digging Depth | 14.79 ft in (4506 mm) |
| Max Digging Depth | 17.07 ft in (5200 mm) |
| Boom/Stick Option (Hex) 1 | Boom 16'11" (5150mm)/Stick 6'1" (1850mm) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 28.09 ft in (8560 mm) |
| Max Cutting Height | 29.01 ft in (8840 mm) |
| Shipping Height Of Unit | 9.72 ft in (2960 mm) |
| Max Loading Height | 20.44 ft in (6230 mm) |
| Max Reach Along Ground | 27.92 ft in (8510 mm) |
| Max Vertical Wall Digging Depth | 16.53 ft in (5036 mm) |
| Max Digging Depth | 18.41 ft in (5610 mm) |
| Boom/Stick Option (Hex) 2 | Boom 16'11" (5150mm)/Stick 7'5" (2250mm) |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 28.09 ft in (8560 mm) |
| Max Cutting Height | 29.2 ft in (8900 mm) |
| Max Loading Height | 20.74 ft in (6320 mm) |
| Shipping Height Of Unit | 9.73 ft in (2965 mm) |
| Max Reach Along Ground | 28.88 ft in (8800 mm) |
| Max Vertical Wall Digging Depth | 18.67 ft in (5690 mm) |
| Max Digging Depth | 19.56 ft in (5960 mm) |
| Boom/Stick Option (Hex) 3 | Boom 16'11" (5150mm)/Stick 8'6" (2600mm) |
Boom/Stick Option (Hex) 4
| Shipping Length Of Unit | 28.12 ft in (8570 mm) |
| Shipping Height Of Unit | 10.03 ft in (3055 mm) |
| Max Cutting Height | 29.71 ft in (9055 mm) |
| Max Loading Height | 21.23 ft in (6470 mm) |
| Max Reach Along Ground | 29.78 ft in (9075 mm) |
| Max Digging Depth | 20.51 ft in (6250 mm) |
| Max Vertical Wall Dig Depth | 18.85 ft in (5743 mm) |
| Boom/Stick Option (Hex) 4 | Boom 16'11" (5150mm)/Stick 9'6" (2900mm) |
Dimensions
| Ground Clearance | 1.46 ft in (442 mm) |
| Height To Top Of Cab | 9.42 ft in (2871 mm) |
| Width To Outside Of Tracks | 9.13 ft in (2780 mm) |
| Length Of Track On Ground | 10.7 ft in (3260 mm) |
| Tail Swing Radius | 7.93 ft in (2417 mm) |
| Removal Counterweight Clearance | 3.38 ft in (1030 mm) |
Undercarriage
| Track Gauge | 7.16 ft in (2180 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Ground Pressure | 6 psi (41.37 kPa) |
| Max Travel Speed | 3.42 mph (5.5 km/h) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2238 |
| Engine Model | SA4D102E |
| Gross Power | 104.6 hp (78 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 239.3 cu in (4 L) |
Operational
| Operating Weight | 39462.8 lb (17900 kg) |
| Fuel Capacity | 66.1 gal (250 L) |
| Hydraulic System Fluid Capacity | 31.8 gal (120 L) |
| Hydraulic System Relief Valve Pressure | 5050 psi (34818.5 kPa) |
| Hydraulic Pump Flow Capacity | 57.1 gal/min (216 L/min) |
Swing Mechanism
| Swing Speed | 12 rpm |
Buckets
| Reference Bucket Capacity | 0.9 yd3 (0.7 m3) |
| Minimum Bucket Capacity | 0.6 yd3 (0.4 m3) |
| Maximum Bucket Capacity | 1.5 yd3 (1.2 m3) |
