Komatsu H455S
Browse All Komatsu or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 69.89 ft in (21300 mm) |
| Shipping Height Of Unit | 39.38 ft in (12000 mm) |
| Max Cutting Height | 60.37 ft in (18400 mm) |
| Max Loading Height | 39.7 ft in (12100 mm) |
| Max Reach Along Ground | 62.67 ft in (19100 mm) |
| Max Vertical Wall Digging Depth | 3.29 ft in (1000 mm) |
| Max Digging Depth | 32.81 ft in (10000 mm) |
| Boom/Stick Option (Hex) 1 | Boom 32'10" (10000mm)/Stick 16'9" (5100mm) |
Dimensions
| Ground Clearance | 3.29 ft in (1000 mm) |
| Height To Top Of Cab | 28.59 ft in (8713 mm) |
| Width To Outside Of Tracks | 23.46 ft in (7150 mm) |
| Length Of Track On Ground | 22.31 ft in (6800 mm) |
| Tail Swing Radius | 24.45 ft in (7450 mm) |
| Removal Counterweight Clearance | 10.54 ft in (3210 mm) |
Undercarriage
| Track Gauge | 19.03 ft in (5800 mm) |
| Shoe Size | 53.15 in (1350 mm) |
| Max Travel Speed | 1.43 mph (2.3 km/h) |
| Ground Pressure | 32 psi (220.64 kPa) |
Engine
| Number Of Cylinders | 12 |
| Engine Make | 2347 |
| Engine Model | KTTA38C x2 |
| Gross Power | 2239.6 hp (1670 kw) |
| Power Measured @ | 1800 rpm |
| Displacement | 4576.8 cu in (75 L) |
Operational
| Operating Weight | 1080265.2 lb (490000 kg) |
| Fuel Capacity | 1954.9 gal (7400 L) |
| Hydraulic System Fluid Capacity | 1003.9 gal (3800 L) |
| Hydraulic System Relief Valve Pressure | 4495 psi (30992 kPa) |
| Hydraulic Pump Flow Capacity | 1157.1 gal/min (4380 L/min) |
Swing Mechanism
| Swing Speed | 3.6 rpm |
