Komatsu H455S
Contents:
Dimensions
| Width Over Tracks | 23.46 ft in (7150 mm) |
| Length Of Track On Ground | 22.31 ft in (6800 mm) |
| Height To Top Of Cab | 28.59 ft in (8713 mm) |
| Tail Swing Radius | 23.5 ft in (7160 mm) |
| Ground Clearance | 39.38 in (1000 mm) |
| Upper Structure Ground Clearance | 10.54 ft in (3210 mm) |
| Length Of Tracks | 29.8 ft in (9082 mm) |
Loading Shovel
| Max Dig Reach | 55.12 ft in (16800 mm) |
| Max Dump Height | 45.94 ft in (14000 mm) |
| Max Cutting Height | 66.77 ft in (20350 mm) |
| Max Dig Depth | 9.85 ft in (3000 mm) |
| Height To Top Of Boom - Shovel | 32.16 ft in (9800 mm) |
| Overall Length - Shovel | 54.63 ft in (16650 mm) |
Undercarriage
| Loading Shovel Shoe Width | 53.15 in (1350 mm) |
| Track Gauge | 19.03 ft in (5800 mm) |
| Max Travel Speed | 1.4 mph (2.26 km/h) |
| Loading Shovel Operating Weight | 1080265.02 lb (490000 kg) |
| Loading Shovel Ground Pressure | 32 psi (220.64 kPa) |
Engine
| Number Of Cylinders | 12 |
| Engine Make | 2347 |
| Engine Model | KTTA38C x2 |
| Net Power | 2236 hp (1667.4 kw) |
| Power Measured @ | 1800 rpm |
| Aspiration | Turbocharged |
| Displacement | 2288 cu in (37.5 L) |
Operational
| Fuel Capacity | 1954.9 gal (7400 L) |
| Hydraulic System Fluid Capacity | 1003.9 gal (3800 L) |
| Swing Speed | 3.6 rpm |
Buckets
| Reference Bucket Capacity | 36.7 yd3 (28 m3) |
