YTO WY10
Browse All YTO or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Max Cutting Height | 18.64 ft in (5680 mm) |
| Max Loading Height | 13.36 ft in (4070 mm) |
| Max Digging Depth | 13.33 ft in (4060 mm) |
Dimensions
| Ground Clearance | 1.15 ft in (350 mm) |
| Height To Top Of Cab | 9.22 ft in (2810 mm) |
| Width To Outside Of Tracks | 7.91 ft in (2410 mm) |
| Length Of Track On Ground | 8.64 ft in (2633 mm) |
| Tail Swing Radius | 6.39 ft in (1945 mm) |
| Removal Counterweight Clearance | 3.22 ft in (980 mm) |
Undercarriage
| Track Gauge | 6.07 ft in (1850 mm) |
| Shoe Size | 15.36 in (390 mm) |
| Max Travel Speed | 7.71 mph (12.4 km/h) |
Engine
| Number Of Cylinders | 4 |
| Engine Model | LR4105ZG56 |
| Net Power | 80.5 hp (60 kw) |
| Power Measured @ | 2200 rpm |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 21605.4 lb (9800 kg) |
| Hydraulic System Relief Valve Pressure | 4061.1 psi (28000 kPa) |
Swing Mechanism
| Swing Speed | 12.4 rpm |
Buckets
| Reference Bucket Capacity | 0.6 yd3 (0.4 m3) |
