New Holland EH160LC
Browse All New Holland or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 28.38 ft in (8650 mm) |
| Shipping Height Of Unit | 9.72 ft in (2960 mm) |
| Max Cutting Height | 31.57 ft in (9620 mm) |
| Max Loading Height | 22.84 ft in (6960 mm) |
| Max Reach Along Ground | 31.17 ft in (9500 mm) |
| Max Vertical Wall Digging Depth | 19.76 ft in (6020 mm) |
| Max Digging Depth | 21.56 ft in (6570 mm) |
| Boom/Stick Option (Hex) 1 | Boom - 17'1" (5.2 m) / Arm - 10'2" (3.1 m) |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 28.38 ft in (8650 mm) |
| Max Cutting Height | 30.19 ft in (9200 mm) |
| Shipping Height Of Unit | 9.68 ft in (2950 mm) |
| Max Loading Height | 21.56 ft in (6570 mm) |
| Max Reach Along Ground | 29.47 ft in (8980 mm) |
| Max Vertical Wall Digging Depth | 17 ft in (5180 mm) |
| Max Digging Depth | 19.92 ft in (6070 mm) |
| Boom/Stick Option (Hex) 2 | Boom - 17'1" (5.2 m) / Arm - 8'6" (2.60 m) |
Dimensions
| Ground Clearance | 1.58 ft in (480 mm) |
| Height To Top Of Cab | 9.68 ft in (2950 mm) |
| Width To Outside Of Tracks | 8.5 ft in (2590 mm) |
| Length Of Track On Ground | 10.77 ft in (3280 mm) |
| Tail Swing Radius | 8.21 ft in (2500 mm) |
| Removal Counterweight Clearance | 3.38 ft in (1030 mm) |
Undercarriage
| Track Gauge | 6.53 ft in (1990 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Ground Pressure | 5.51 psi (38 kPa) |
| Drawbar Pull | 35100 lb (156 kN) |
| Max Travel Speed | 3.7 mph (6 km/h) |
Engine
| Engine Make | 2251 |
| Engine Model | 4D34-TEG |
| Net Power | 112 hp (83.6 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 238 cu in (4 L) |
Operational
| Operating Weight | 36800 lb (16700 kg) |
| Fuel Capacity | 74.2 gal (281 L) |
| Cooling System Fluid Capacity | 5 gal (19 L) |
| Hydraulic System Fluid Capacity | 42 gal (159 L) |
| Operating Voltage | 12 V |
| Engine Oil Capacity | 4 gal (15 L) |
| Alternator Supplied Amperage | 35 amps |
| Hydraulic System Relief Valve Pressure | 4980 psi (34335.9 kPa) |
| Hydraulic Pump Flow Capacity | 80.8 gal/min (305.9 L/min) |
Swing Mechanism
| Swing Torque | 38722.1 lb ft (52500 Nm) |
| Swing Speed | 11 rpm |
Buckets
| Reference Bucket Capacity | 0.8 yd3 (0.6 m3) |
| Minimum Bucket Capacity | 0.5 yd3 (0.4 m3) |
| Maximum Bucket Capacity | 1.4 yd3 (1.1 m3) |
