New Holland E200SRLC
Browse All New Holland or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 26.42 ft in (8050 mm) |
| Shipping Height Of Unit | 10.04 ft in (3060 mm) |
| Max Cutting Height | 33.57 ft in (10230 mm) |
| Max Loading Height | 24.15 ft in (7360 mm) |
| Max Reach Along Ground | 28.88 ft in (8800 mm) |
| Max Vertical Wall Digging Depth | 15.46 ft in (4710 mm) |
| Max Digging Depth | 20.18 ft in (6150 mm) |
| Boom/Stick Option (Hex) 1 | stick 2600mm |
Boom/Stick Option (Hex) 2
| Max Cutting Height | 34.55 ft in (10530 mm) |
| Shipping Height Of Unit | 10.04 ft in (3060 mm) |
| Max Loading Height | 25.14 ft in (7660 mm) |
| Max Reach Along Ground | 30.16 ft in (9190 mm) |
| Max Vertical Wall Digging Depth | 16.77 ft in (5110 mm) |
| Max Digging Depth | 21.49 ft in (6550 mm) |
| Boom/Stick Option (Hex) 2 | stick 3000mm |
Dimensions
| Ground Clearance | 1.48 ft in (450 mm) |
| Height To Top Of Cab | 10.04 ft in (3060 mm) |
| Width To Outside Of Tracks | 9.81 ft in (2990 mm) |
| Length Of Track On Ground | 12.01 ft in (3660 mm) |
| Tail Swing Radius | 5.29 ft in (1610 mm) |
| Removal Counterweight Clearance | 3.38 ft in (1030 mm) |
Undercarriage
| Track Gauge | 11.06 ft in (3370 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Max Travel Speed | 3.11 mph (5 km/h) |
| Number Of Carrier Rollers Per Side | 2 |
| Ground Pressure | 6.24 psi (43 kPa) |
| Number Of Track Rollers Per Side | 8 |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2353 |
| Engine Model | - 4BG1TXBFA |
| Net Power | 125 hp (93.3 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 264.2 cu in (4.4 L) |
| Aspiration | turbo, intercooler |
Operational
| Operating Weight | 44974.3 lb (20400 kg) |
| Fuel Capacity | 71.4 gal (270 L) |
| Cooling System Fluid Capacity | 4.9 gal (18.5 L) |
| Hydraulic System Fluid Capacity | 44.2 gal (167 L) |
| Engine Oil Capacity | 3.5 gal (13 L) |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 2 gal (7.5 L) |
| Alternator Supplied Amperage | 30 amps |
| Hydraulic System Relief Valve Pressure | 5076.4 psi (35000 kPa) |
| Hydraulic Pump Flow Capacity | 93 gal/min (352 L/min) |
Swing Mechanism
| Swing Speed | 11 rpm |
Buckets
| Reference Bucket Capacity | 0.9 yd3 (0.7 m3) |
| Minimum Bucket Capacity | 0.7 yd3 (0.6 m3) |
| Maximum Bucket Capacity | 1.1 yd3 (0.8 m3) |
