New Holland E195LC
Browse All New Holland or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 29.11 ft in (8870 mm) |
| Shipping Height Of Unit | 9.91 ft in (3020 mm) |
| Max Cutting Height | 29.77 ft in (9073 mm) |
| Max Loading Height | 20.64 ft in (6290 mm) |
| Max Reach Along Ground | 27.89 ft in (8499 mm) |
| Max Vertical Wall Digging Depth | 17.86 ft in (5443 mm) |
| Max Digging Depth | 18.75 ft in (5714 mm) |
| Boom/Stick Option (Hex) 1 | monobloc boom / stick 2200mm |
Boom/Stick Option (Hex) 2
| Shipping Length Of Unit | 28.81 ft in (8780 mm) |
| Max Cutting Height | 30.8 ft in (9385 mm) |
| Shipping Height Of Unit | 9.75 ft in (2970 mm) |
| Max Loading Height | 21.43 ft in (6531 mm) |
| Max Reach Along Ground | 29.22 ft in (8904 mm) |
| Max Vertical Wall Digging Depth | 19.31 ft in (5885 mm) |
| Max Digging Depth | 20.07 ft in (6115 mm) |
| Boom/Stick Option (Hex) 2 | monobloc boom / stick 2600mm |
Boom/Stick Option (Hex) 3
| Shipping Length Of Unit | 28.81 ft in (8780 mm) |
| Max Cutting Height | 32.11 ft in (9785 mm) |
| Max Loading Height | 22.65 ft in (6903 mm) |
| Shipping Height Of Unit | 9.95 ft in (3030 mm) |
| Max Reach Along Ground | 30.93 ft in (9427 mm) |
| Max Vertical Wall Digging Depth | 21.11 ft in (6432 mm) |
| Max Digging Depth | 21.7 ft in (6614 mm) |
| Boom/Stick Option (Hex) 3 | monobloc boom / stick 3100mm |
Dimensions
| Ground Clearance | 1.54 ft in (468 mm) |
| Height To Top Of Cab | 9.75 ft in (2970 mm) |
| Width To Outside Of Tracks | 9.19 ft in (2800 mm) |
| Length Of Track On Ground | 11.06 ft in (3370 mm) |
| Tail Swing Radius | 8.57 ft in (2610 mm) |
| Removal Counterweight Clearance | 3.51 ft in (1069 mm) |
Undercarriage
| Track Gauge | 7.22 ft in (2200 mm) |
| Shoe Size | 23.63 in (600 mm) |
| Number Of Track Rollers Per Side | 7 |
| Ground Pressure | 6.82 psi (47 kPa) |
| Max Travel Speed | 3.11 mph (5 km/h) |
| Number Of Carrier Rollers Per Side | 2 |
Engine
| Number Of Cylinders | 4 |
| Engine Model | CNH F4BE0484D*D608 |
| Net Power | 130 hp (97 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 332 lb ft (450 Nm) |
| Aspiration | turbocharged and intercooler |
| Displacement | 238 cu in (3.9 L) |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 41755.6 lb (18940 kg) |
| Fuel Capacity | 43.6 gal (165 L) |
| Cooling System Fluid Capacity | 4.8 gal (18 L) |
| Hydraulic System Fluid Capacity | 39.7 gal (150 L) |
| Engine Oil Capacity | 4 gal (15 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 amps |
| Hydraulic System Relief Valve Pressure | 4974.8 psi (34300 kPa) |
| Hydraulic Pump Flow Capacity | 93 gal/min (352 L/min) |
Swing Mechanism
| Swing Speed | 10 rpm |
Buckets
| Reference Bucket Capacity | 1.1 yd3 (0.8 m3) |
| Minimum Bucket Capacity | 0.7 yd3 (0.6 m3) |
| Maximum Bucket Capacity | 1.5 yd3 (1.1 m3) |
