Mustang ME 12002
Browse All Mustang or Hydraulic Excavator Models
Contents:
Boom/Stick Option (Hex) 1
| Shipping Length Of Unit | 23.25 ft in (7087 mm) |
| Shipping Height Of Unit | 9.17 ft in (2794 mm) |
| Max Cutting Height | 26.17 ft in (7976 mm) |
| Max Loading Height | 19.33 ft in (5893 mm) |
| Max Reach Along Ground | 24.67 ft in (7518 mm) |
| Max Vertical Wall Digging Depth | 17.33 ft in (5283 mm) |
| Max Digging Depth | 15.67 ft in (4775 mm) |
| Boom/Stick Option (Hex) 1 | Standard Arm Length 7ft. 10.5in. (2400mm ) |
Dimensions
| Ground Clearance | 1.38 ft in (419 mm) |
| Height To Top Of Cab | 9.17 ft in (2794 mm) |
| Width To Outside Of Tracks | 7.83 ft in (2400 mm) |
| Length Of Track On Ground | 8.67 ft in (2642 mm) |
| Tail Swing Radius | 5.42 ft in (1651 mm) |
| Removal Counterweight Clearance | 2 ft in (610 mm) |
Undercarriage
| Shoe Size | 19.7 in (500 mm) |
| Max Travel Speed | 3.9 mph (6.2 km/h) |
| Drawbar Pull | 29542 lb (131.4 kN) |
| Number Of Carrier Rollers Per Side | 1 |
| Number Of Track Rollers Per Side | 6 |
| Ground Pressure | 6.11 psi (42.13 kPa) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2240 |
| Engine Model | 4045TF270 |
| Gross Power | 99 hp (74 kw) |
| Net Power | 90 hp (67 kw) |
| Displacement | 276 cu in (4.5 L) |
Operational
| Operating Weight | 25397 lb (11519.9 kg) |
| Hydraulic System Relief Valve Pressure | 3770 psi (25993.3 kPa) |
| Hydraulic Pump Flow Capacity | 69.2 gal/min (262 L/min) |
Swing Mechanism
| Swing Torque | 16276 lb ft (72.3 Nm) |
| Swing Speed | 11 rpm |
Buckets
| Reference Bucket Capacity | 0.6 yd3 (0.4 m3) |
| Minimum Bucket Capacity | 0.6 yd3 (0.4 m3) |
| Maximum Bucket Capacity | 0.9 yd3 (0.7 m3) |
