John Deere 1063
Browse All John Deere or Harvester Models
Contents:
Boom
| Max Reach W/ Head | 32.67 ft in (9957.82 mm) |
Dimensions
| Overall Width | 9.13 ft in (2780 mm) |
| Wheelbase | 11.49 ft in (3500 mm) |
| Height To Top Of Cab | 11.95 ft in (3640 mm) |
Undercarriage
| Ground Clearance | 1.97 ft in (600 mm) |
| Ground Pressure | 7.5 psi (51.72 kPa) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2347 |
| Engine Model | 6BTA5.9 |
| Gross Power | 165 hp (123.1 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 360.1 cu in (5.9 L) |
| Max Torque | 511.9 lb ft (694 Nm) |
| Torque Measured @ | 1500 rpm |
| Aspiration | Turbocharged and aftercooled |
Operational
| Operating Weight | 30423.8 lb (13800 kg) |
| Fuel Capacity | 79.3 gal (300 L) |
| Hydraulic System Fluid Capacity | 52.9 gal (200 L) |
| Cooling System Fluid Capacity | 7.7 gal (29 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 amps |
| Max Speed | 15.6 mph (25 km/h) |
| Transmission Type | Hydrostatic mechanical with two speed gearbox |
Drive System
| Tire Size - Front | 700 x 26.5 ELS |
| Tire Size - Rear | 750 x 26.5 TRS |
