John Deere 853JH
Browse All John Deere or Harvester Models
Contents:
Boom
| Max Reach W/ Head | 29 ft in (8839.21 mm) |
| Lift Capacity At Max Reach | 13999.36 lb (6350 kg) |
Dimensions
| Overall Width | 10.41 ft in (3170 mm) |
| Height To Top Of Cab | 11.49 ft in (3500 mm) |
Undercarriage
| Track Length | 14.47 ft in (4410 mm) |
| Ground Clearance | 2.3 ft in (700 mm) |
| Track Gauge | 8.4 ft in (2560 mm) |
| Shoe Size | 24.02 in (610 mm) |
| Number Of Track Rollers Per Side | 8 |
| Ground Pressure | 8.64 psi (59.58 kPa) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 6081H, Tier II |
| Net Power | 274 hp (204.4 kw) |
| Gross Power | 294 hp (219.3 kw) |
| Power Measured @ | 2000 rpm |
| Displacement | 492 cu in (8.1 L) |
| Max Torque | 885 lb ft (1199.9 Nm) |
| Torque Measured @ | 1400 rpm |
Operational
| Operating Weight | 60516.9 lb (27450 kg) |
| Fuel Capacity | 295.1 gal (1117 L) |
| Hydraulic System Fluid Capacity | 82.2 gal (311 L) |
| Engine Oil Capacity | 7.4 gal (28 L) |
| Cooling System Fluid Capacity | 11.1 gal (42 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
| Max Speed | 3.2 mph (5 km/h) |
