Komatsu 860.3
Contents:
Dimensions
| Length | 30.5 ft in (9296 mm) |
| Wheelbase | 21.78 ft in (6637 mm) |
| Width Over Tires | 8.94 ft in (2722 mm) |
| Height To Top Of Crane | 12.5 ft in (3809 mm) |
| Ground Clearance | 2.25 ft in (683 mm) |
| Length Of Bunk Area | 4.93 ft in (1500 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Model | 66 CTA |
| Power | 188 hp (140.2 kw) |
| Torque | 594 lb ft (805.4 Nm) |
| Power Measured @ | 2200 rpm |
| Displacement | 402.8 cu in (6.6 L) |
| Torque Measured @ | 1500 rpm |
| Aspiration | Turbo |
Operational
| Operating Weight - 6wd | 31658.4 lb (14360 kg) |
| Operating Weight - 8wd | 34965.4 lb (15860 kg) |
| Fuel Capacity | 42.3 gal (160 L) |
| Hydraulic System Fluid Capacity | 26.5 gal (100 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 amps |
| Front/Rear Tire Size - 6wd | 600/65x34, 600/55x26.5 |
| Front/Rear Tire Size - 8wd | 600/55x26.5, 600/55x26.5 |
Transmission
| Transmission Type | Hydrostatic |
| Max Speed | 14.7 mph (23.5 km/h) |
Hydraulic
| Pump Type | single circuit load sensing with variable piston pump |
| Flow Capacity | 76.7 gal/min (290 L/min) |
| Relief Valve Pressure | 3400 psi (23442.2 kPa) |
Bunk
| Load Weight - 6wd | 30864.8 lb (14000 kg) |
| Load Weight - 8wd | 30864.8 lb (14000 kg) |
| Load Area | 48.5 ft2 (4.5 m2) |
Crane
| Crane Type | CRF 10 |
| Max Reach | 25.6 ft in (7800 mm) |
| Gross Lift Torque | 84700 lb ft (114837.8 Nm) |
| Gross Slew Torque | 21170 lb ft (28702.7 Nm) |
