John Deere 1710D
Browse All John Deere or Forwarder Models
Contents:
Dimensions
| Length | 35.6 ft in (10850 mm) |
| Wheelbase | 19.36 ft in (5900 mm) |
| Width Over Tires | 10.47 ft in (3190 mm) |
| Height To Top Of Crane | 12.8 ft in (3900 mm) |
| Ground Clearance | 2.4 ft in (730 mm) |
| Length Of Bunk Area | 18.25 ft in (5560 mm) |
| Width Of Bunk Area | 9.67 ft in (2950 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2240 |
| Engine Model | 6081H |
| Power | 215 hp (160.4 kw) |
| Torque | 811 lb ft (1099.6 Nm) |
| Power Measured @ | 2000 rpm |
| Displacement | 494 cu in (8.1 L) |
| Torque Measured @ | 1300 rpm |
| Aspiration | turbocharged |
Operational
| Operating Weight - 8wd | 42990 lb (19500 kg) |
| Fuel Capacity | 48 gal (181.7 L) |
| Hydraulic System Fluid Capacity | 50 gal (189.3 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 amps |
| Front/Rear Tire Size - 8wd | 750x26.5/750x26.5 |
Transmission
| Transmission Type | hydrostatic/mechanical |
| Number Of Forward Gears | 2 |
| Number Of Reverse Gears | 2 |
| Max Speed | 14.3 mph (23.1 km/h) |
Hydraulic
| Pump Type | variable displacement |
| Flow Capacity | 55.5 gal/min (210.1 L/min) |
| Relief Valve Pressure | 3480 psi (23993.8 kPa) |
Bunk
| Load Weight - 8wd | 37480 lb (17000.7 kg) |
| Load Area | 58.2 ft2 (5.4 m2) |
Crane
| Crane Type | Timberjack CF 8 85 |
| Max Reach | 27.9 ft in (8500 mm) |
| Gross Lift Torque | 111371.9 lb ft (151000 Nm) |
| Gross Slew Torque | 30240.1 lb ft (41000 Nm) |
