Yale HLF25-5
Contents:
Dimensions
| Length To Fork Face | 8.55 ft in (2605 mm) |
| Overall Width | 3.81 ft in (1160 mm) |
| Overall Height - Mast Lowered | 7.14 ft in (2175 mm) |
| Wheelbase | 5.42 ft in (1650 mm) |
| Ground Clearance | 7.25 in (184 mm) |
| Height To Top Of Overhead Guard | 7.16 ft in (2180 mm) |
| Max Fork Height | 14.72 ft in (4485 mm) |
| Turning Radius | 7.63 ft in (2325 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 10 degrees |
| Lower Speed | 91 ft/min (27.74 m/min) |
| Load Capacity | 5000 lb (2267.97 kg) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 126 ft/min (38.41 m/min) |
Engine
| Engine Make | 2251 |
| Engine Model | 4G64-33HL |
| Power | 49.4 hp (36.8 kw) |
| Torque | 123 lb ft (166.8 Nm) |
| Power Measured @ | 2500 rpm |
| Displacement | 143 cu in (2.4 L) |
| Torque Measured @ | 1600 rpm |
Operational
| Operating Weight | 8510 lb (3860.1 kg) |
| Max Speed | 12.7 mph (20.5 km/h) |
