Yale HDF25-5
Contents:
Dimensions
| Length To Fork Face | 8.55 ft in (2605 mm) |
| Overall Width | 4.99 ft in (1520 mm) |
| Overall Height - Mast Lowered | 7.14 ft in (2175 mm) |
| Wheelbase | 5.42 ft in (1650 mm) |
| Ground Clearance | 7.25 in (184 mm) |
| Height To Top Of Overhead Guard | 7.16 ft in (2180 mm) |
| Max Fork Height | 14.72 ft in (4485 mm) |
| Turning Radius | 7.63 ft in (2325 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 10 degrees |
| Lower Speed | 89 ft/min (27.13 m/min) |
| Load Capacity | 5000 lb (2267.97 kg) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 136 ft/min (41.46 m/min) |
Engine
| Engine Make | 2348 |
| Engine Model | 4TNE98 |
| Power | 61.7 hp (46 kw) |
| Torque | 152 lb ft (206.1 Nm) |
| Power Measured @ | 2300 rpm |
| Displacement | 202.5 cu in (3.4 L) |
| Torque Measured @ | 1700 rpm |
Operational
| Operating Weight | 9096 lb (4125.9 kg) |
| Max Speed | 12.1 mph (19.5 km/h) |
