TCM FHD18T9
Contents:
Dimensions
| Overall Width | 3.51 ft in (1069.24 mm) |
| Overall Height - Mast Lowered | 6.8 ft in (2069.9 mm) |
| Max Fork Height | 10.84 ft in (3301.9 mm) |
| Turning Radius | 6.6 ft in (2009.25 mm) |
Mast
| Lift Speed | 129.9 ft/min (39.6 m/min) |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 3500 lb (1587.58 kg) |
Engine
| Engine Model | C240 |
| Power | 49.7 hp (37 kw) |
| Displacement | 144.6 cu in (2.4 L) |
| Fuel Type | diesel |
Operational
| Operating Weight | 6290 lb (2853.1 kg) |
| Tire Type | pneumatic |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 12.1 mph (19.5 km/h) |
