Noveltek FBF-20
Contents:
Dimensions
| Overall Width | 3.52 ft in (1070 mm) |
| Overall Height - Mast Lowered | 6.67 ft in (2030 mm) |
| Wheelbase | 4.2 ft in (1280 mm) |
| Height To Top Of Overhead Guard | 6.86 ft in (2090 mm) |
| Max Fork Height | 9.85 ft in (3000 mm) |
| Turning Radius | 6.11 ft in (1860 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 12 degrees |
| Lower Speed | 79.73 ft/min (24.3 m/min) |
| Lift Speed | 108.27 ft/min (33 m/min) |
| Number Of Mast Sections | 2 |
| Load Center | 19.69 in (500 mm) |
| Load Capacity | 4409.25 lb (2000 kg) |
Engine
| Power | 10.8 hp (8 kw) |
| Fuel Type | battery |
Operational
| Operating Weight | 7716.2 lb (3500 kg) |
| Tire Type | pneumatic shaped soft solid front 6.50x10 rear 5.00x8 |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 7.5 mph (12 km/h) |
