Manitou MSI 30LPG
Contents:
Dimensions
| Length To Fork Face | 9.75 ft in (2971.8 mm) |
| Overall Width | 4.92 ft in (1498.61 mm) |
| Overall Height - Mast Lowered | 7.56 ft in (2303.78 mm) |
| Wheelbase | 5.92 ft in (1803.41 mm) |
| Ground Clearance | 9.5 in (241.3 mm) |
| Height To Top Of Overhead Guard | 6.92 ft in (2108.21 mm) |
| Max Fork Height | 15.42 ft in (4700.02 mm) |
| Turning Radius | 8 ft in (2438.4 mm) |
Mast
| Mast Tip Forward | 10 degrees |
| Mast Tip Rear | 12 degrees |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 6000 lb (2721.56 kg) |
Engine
| Engine Make | 2304 |
| Engine Model | 4Y |
| Power | 53 hp (39.6 kw) |
| Displacement | 136.5 cu in (2.3 L) |
| Torque Measured @ | 2200 rpm |
| Fuel Type | PROGANE |
Operational
| Operating Weight | 9987 lb (4530 kg) |
| Tire Type | 14x17.5, 7x12 |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 13 mph (21 km/h) |
