John Deere 482D
Browse All John Deere or Forklift Models
Contents:
Dimensions
| Length To Fork Face | 12.14 ft in (3700 mm) |
| Overall Width | 7.09 ft in (2160 mm) |
| Overall Height - Mast Lowered | 9.68 ft in (2950 mm) |
| Wheelbase | 6.89 ft in (2100 mm) |
| Ground Clearance | 25.99 in (660 mm) |
| Max Fork Height | 16.77 ft in (5110 mm) |
| Turning Radius | 11.98 ft in (3650 mm) |
Mast
| Mast Tip Forward | 15 degrees |
| Mast Tip Rear | 11 degrees |
| Lift Speed | 72 ft/min (21.95 m/min) |
| Number Of Mast Sections | 2 |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 6000 lb (2721.56 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2240 |
| Engine Model | 4039D |
| Power | 63 hp (47 kw) |
| Torque | 172 lb ft (233.3 Nm) |
| Power Measured @ | 2200 rpm |
| Displacement | 239 cu in (4 L) |
| Torque Measured @ | 1350 rpm |
Operational
| Operating Weight | 12400 lb (5624.6 kg) |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 20.7 mph (33.4 km/h) |
