John Deere JD480-A
Browse All John Deere or Forklift Models
Contents:
Dimensions
| Length To Fork Face | 12.6 ft in (3840 mm) |
| Overall Width | 6.6 ft in (2010 mm) |
| Overall Height - Mast Lowered | 9.68 ft in (2950 mm) |
| Wheelbase | 6.83 ft in (2080 mm) |
| Max Fork Height | 14.01 ft in (4270 mm) |
| Turning Radius | 10.83 ft in (3300 mm) |
Mast
| Mast Tip Forward | 19 degrees |
| Mast Tip Rear | 9 degrees |
| Lower Speed | 29 ft/min (8.84 m/min) |
| Lift Speed | 57 ft/min (17.38 m/min) |
| Number Of Mast Sections | 2 |
| Load Center | 24 in (609.6 mm) |
| Load Capacity | 6000 lb (2721.56 kg) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2240 |
| Power | 59 hp (44 kw) |
| Power Measured @ | 2500 rpm |
| Fuel Type | Diesel |
Operational
| Operating Weight | 10980 lb (4980.5 kg) |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 21.7 mph (35 km/h) |
