EP CPCD40
Contents:
Dimensions
| Length To Fork Face | 10.08 ft in (3070 mm) |
| Overall Width | 4.58 ft in (1395 mm) |
| Overall Height - Mast Lowered | 7.37 ft in (2245 mm) |
| Wheelbase | 6.57 ft in (2000 mm) |
| Ground Clearance | 6.7 in (170 mm) |
| Height To Top Of Overhead Guard | 7.39 ft in (2250 mm) |
| Max Fork Height | 13.69 ft in (4170 mm) |
| Right Angle Stack | 10.63 ft in (3240 mm) |
| Turning Radius | 8.83 ft in (2690 mm) |
Mast
| Mast Tip Forward | 6 degrees |
| Mast Tip Rear | 12 degrees |
| Load Capacity | 8818.5 lb (4000 kg) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 90.56 ft/min (27.6 m/min) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2311 |
| Engine Model | TD42 |
| Power | 83.9 hp (62.5 kw) |
| Torque | 202.4 lb ft (274.4 Nm) |
| Power Measured @ | 2300 rpm |
| Displacement | 254.5 cu in (4.2 L) |
| Torque Measured @ | 1600 rpm |
| Fuel Type | diesel |
Operational
| Operating Weight | 13889.2 lb (6300 kg) |
| Tire Type | front 8.25-15-14PR rear 7.00-12-12PR |
| Max Speed | 16.2 mph (26 km/h) |
