BT C4E300NV
Contents:
Dimensions
| Length To Fork Face | 7.07 ft in (2152 mm) |
| Overall Width | 3.75 ft in (1140 mm) |
| Overall Height - Mast Lowered | 7.3 ft in (2225 mm) |
| Wheelbase | 5.06 ft in (1540 mm) |
| Ground Clearance | 4.18 in (106 mm) |
| Height To Top Of Overhead Guard | 7.57 ft in (2307 mm) |
| Max Fork Height | 10.37 ft in (3160 mm) |
| Turning Radius | 7.09 ft in (2158 mm) |
Mast
| Mast Tip Forward | 2.3 degrees |
| Mast Tip Rear | 6 degrees |
| Lower Speed | 118.12 ft/min (36 m/min) |
| Load Capacity | 6613.87 lb (3000 kg) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 92.52 ft/min (28.2 m/min) |
Engine
| Power | 18.8 hp (14 kw) |
| Fuel Type | electric |
Operational
| Operating Weight | 11706.6 lb (5310 kg) |
| Tire Type | front 23x10-12 rear 18x7-8 |
| Number Of Front Wheels | 2 |
| Number Of Rear Wheels | 2 |
| Max Speed | 10.3 mph (16.5 km/h) |
