BT C4D450E
Contents:
Dimensions
| Length To Fork Face | 9.7 ft in (2954 mm) |
| Overall Width | 4.63 ft in (1410 mm) |
| Overall Height - Mast Lowered | 7.88 ft in (2400 mm) |
| Wheelbase | 6.24 ft in (1900 mm) |
| Ground Clearance | 5.91 in (150 mm) |
| Height To Top Of Overhead Guard | 8.14 ft in (2480 mm) |
| Max Fork Height | 10.34 ft in (3150 mm) |
| Turning Radius | 9.05 ft in (2757 mm) |
Mast
| Mast Tip Forward | 5 degrees |
| Mast Tip Rear | 10 degrees |
| Lower Speed | 118.12 ft/min (36 m/min) |
| Load Capacity | 9920.81 lb (4500 kg) |
| Load Center | 19.69 in (500 mm) |
| Lift Speed | 108.27 ft/min (33 m/min) |
Engine
| Engine Make | 2240 |
| Engine Model | e 4045D |
| Power | 75.1 hp (56 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 274.7 cu in (4.5 L) |
| Fuel Type | diesel |
Operational
| Operating Weight | 14638.7 lb (6640 kg) |
| Tire Type | 250-15 |
| Number Of Front Wheels | 2-4 |
| Number Of Rear Wheels | 2 |
| Max Speed | 11.2 mph (18 km/h) |
