Ezee-On 8550
Contents:
Dimensions
| Transport Width | 18 ft in (5486.4 mm) |
| Max Weight | 14715 lb (6674.62 kg) |
| Min Weight | 11894 lb (5395.03 kg) |
| Pto Power Required Per Width Ft. | 25 hp (18.65 kw) |
| Working Width Spacing #1 Max | 15.5 ft in (4724.4 mm) |
| Working Width Spacing #1 Min | 10.5 ft in (3200.4 mm) |
| Working Width Spacing #2 Max | 15.5 ft in (4724.4 mm) |
| Main Frame Tires | 11Lx15FI |
| Working Width Spacing #2 Min | 10.5 ft in (3200.4 mm) |
Disc System
| Spacing #1 | 9 in (228.6 mm) |
| Spacing #2 | 14 in (355.6 mm) |
| Blade Diameter | 32 in (812.8 mm) |
| Blade Thickness | 0.5 in (12 mm) |
| Depth Control | single 4"x12" Hyd. Cyl. |
| Weight Per Blade Spacing #1 | 582 lb (264 kg) |
| Weight Per Blade Spacing #2 | 582 lb (264 kg) |
Gangs
| Gang Spool Type | steel fabricated c/w locking drive lug half spools |
| Front Disk Angle | 25 degrees |
| Rear Disk Angle | 25 degrees |
| Bearing Type | T2-215 series |
| Scrapers | 4"x3/4" steel |
