Hitachi DX195L
Browse All Hitachi or Crawler Tractor Models
Contents:
Dimensions
| Length W/ Blade | 16.68 ft in (5083 mm) |
| Width Over Tracks | 13.32 ft in (4057 mm) |
| Height To Top Of Cab | 10.51 ft in (3203 mm) |
| Length Of Track On Ground | 8.54 ft in (2600 mm) |
Undercarriage
| Track Gauge | 6.14 ft in (1870 mm) |
| Standard Shoe Size | 24 in (609.6 mm) |
| Number Of Track Rollers Per Side | 7 |
| Number Of Carrier Rollers Per Side | 2 |
| Number Of Shoes Per Side | 41 |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2388 |
| Engine Model | 8365T |
| Net Power | 165 hp (123.1 kw) |
| Max Torque | 503 lb ft (682 Nm) |
| Displacement | 494.3 cu in (8.1 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | turbocharged |
Operational
| Operating Weight | 43497.3 lb (19730 kg) |
| Fuel Capacity | 91.2 gal (345 L) |
| Cooling System Fluid Capacity | 10.6 gal (40 L) |
| Engine Oil Capacity | 4 gal (15 L) |
| Final Drives Fluid Capacity | 4.8 gal (18 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 amps |
Transmission
| Transmission Type | full power shift countershaft constant mesh |
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 5.8 mph (9.4 km/h) |
| Max Speed - Reverse | 7 mph (11.3 km/h) |
Hydraulic System
| Pump Type | gear type |
| Relief Valve Pressure | 2700 psi (18615.9 kPa) |
| Pump Flow Capacity | 42.8 gal/min (162 L/min) |
Standard Blade
| Width | 13.4 ft in (4057 mm) |
| Height | 40.6 in (1030 mm) |
| Capacity | 4.2 yd3 (3.2 m3) |
| Blade Angle (Both Directions) | 10 degrees |
| Cutting Depth | 17.8 in (452 mm) |
