Salford TX66
Contents:
Dimensions
| Overall Length | 26.65 ft in (8120 mm) |
| Width Over Tires | 12.96 ft in (3950 mm) |
| Height To Top Of Isomount Cab | 12.96 ft in (3950 mm) |
Engine
| Engine Model | NH 675 TA/CB |
| Power | 238 hp (177.5 kw) |
| Power Measured @ | 2100 rpm |
Operational
| Operating Weight W/O Attachment | 23754.9 lb (10775 kg) |
| Fuel Capacity | 158.6 gal (600 L) |
| Transmission Type | hydrostatic |
| Number Of Gears | 4 |
Threshing
| Rotor Diameter | 23.9 in (606 mm) |
| Rotor Length | 61.5 in (1560 mm) |
| Rotor Speed - Low | 385 rpm |
| Rotor Speed - High | 1140 rpm |
| Concave Area | 1333.1 in2 (0.9 m2) |
| Beater Grate Area | 930.1 in2 (0.6 m2) |
Separating
| Separator Type | rotary |
Cleaning System
| Total Cleaning Area | 10075.1 in2 (6.5 m2) |
| Cleaning Fan Speed - Low | 435 rpm |
| Cleaning Fan Speed - High | 860 rpm |
Grain Handling
| Grain Tank Capacity | 227.1 bu (8000 L) |
| Unloading Speed | 2.1 bu/sec (72 L/sec) |
