Salford TC5050
Contents:
Dimensions
| Overall Length | 26.69 ft in (8135 mm) |
| Width Over Tires | 10.88 ft in (3315 mm) |
Engine
| Engine Make | 2249 |
| Engine Model | 6.8 I |
| Power | 170 hp (126.8 kw) |
| Power Boost Power | 175 hp (130.5 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 415 cu in (6.8 L) |
Operational
| Operating Weight W/O Attachment | 16755.2 lb (7600 kg) |
| Fuel Capacity | 79.3 gal (300 L) |
| Transmission Type | hydro |
| Number Of Gears | 4 |
Threshing
| Rotor Diameter | 23.9 in (607 mm) |
| Rotor Length | 41 in (1040 mm) |
| Rotor Speed - Low | 430 rpm |
| Rotor Speed - High | 1070 rpm |
Separating
| Separator Type | rotary |
Cleaning System
| Total Cleaning Area | 5068.6 in2 (3.3 m2) |
| Cleaning Fan Speed - Low | 350 rpm |
| Cleaning Fan Speed - High | 1000 rpm |
| Self Leveling? | 23% |
Grain Handling
| Grain Tank Capacity | 113.6 bu (4000 L) |
| Unloading Speed | 1.8 bu/sec (60 L/sec) |
