Salford TC5070
Contents:
Dimensions
| Overall Length | 26.69 ft in (8135 mm) |
| Width Over Tires | 10.42 ft in (3173 mm) |
Engine
| Engine Make | 2249 |
| Engine Model | 6.8 I |
| Power | 207 hp (154.4 kw) |
| Power Boost Power | 223 hp (166.3 kw) |
| Power Measured @ | 2100 rpm |
| Displacement | 415 cu in (6.8 L) |
Operational
| Operating Weight W/O Attachment | 19224.4 lb (8720 kg) |
| Fuel Capacity | 105.7 gal (400 L) |
| Transmission Type | hydro |
| Number Of Gears | 4 |
Threshing
| Rotor Diameter | 23.9 in (607 mm) |
| Rotor Length | 51.2 in (1300 mm) |
| Rotor Speed - Low | 417 rpm |
| Rotor Speed - High | 1037 rpm |
| Concave Area | 1224.6 in2 (0.8 m2) |
Separating
| Separator Type | rotary |
| Separator Length | 23.9 in (605 mm) |
| Separating Area | 6758.1 in2 (4.4 m2) |
Cleaning System
| Total Cleaning Area | 6386.1 in2 (4.2 m2) |
| Cleaning Fan Speed - Low | 340 rpm |
| Cleaning Fan Speed - High | 970 rpm |
| Self Leveling? | 23% |
Grain Handling
| Grain Tank Capacity | 147.6 bu (5200 L) |
| Unloading Speed | 1.8 bu/sec (60 L/sec) |
