Haulotte H25TPX
Contents:
Dimensions
| Overall Length | 42.98 in (13100 mm) |
| Overall Width | 8.14 ft in (2480 mm) |
| Overall Height - Mast Lowered | 9.85 ft in (3000 mm) |
| Wheelbase | 8.17 ft in (2490 mm) |
| Ground Clearance | 13.78 in (350 mm) |
| Turning Radius | 20.18 ft in (6150 mm) |
Platform
| Max Platform Height | 76.45 ft in (23300 mm) |
| Max Horizontal Reach | 55.45 ft in (16900 mm) |
| Platform Rotation | 180 degrees |
| Platform Inner Length | 70.87 in (1800 mm) |
| Max Platform Weight Capacity | 507.07 lb (230 kg) |
| Max Working Height | 83.01 ft in (25300 mm) |
| Platform Inner Width | 31.5 in (800 mm) |
Engine
| Engine Make | 2360 |
| Gross Power | 43.1 hp (32.1 kw) |
| Fuel Type | Diesel |
Operational
| Operating Weight | 30247.5 lb (13720 kg) |
| Fuel Capacity | 39.7 gal (150 L) |
| Hydraulic System Fluid Capacity | 39.7 gal (150 L) |
| Max Speed | 3.2 mph (5 km/h) |
| Tire Size | 15 R 22 |
| Tire Fill/Type | foam filled |
