Haulotte 45 XA
Contents:
Dimensions
| Overall Length | 218.4 in (5547.36 mm) |
| Overall Width | 5.6 ft in (1706.88 mm) |
| Overall Height - Mast Lowered | 6.7 ft in (2042.16 mm) |
| Wheelbase | 8.9 ft in (2712.72 mm) |
| Ground Clearance | 6 in (152.4 mm) |
| Outrigger Footprint Length | 11.4 ft in (3.48 m) |
| Lift Capacity To Full Height | 500 lb (226.8 kg) |
| Gradeability | 45 % |
| Turning Radius | 5.4 ft in (1645.92 mm) |
| Up And Over Height | 20.9 ft in (6.38 m) |
Platform
| Max Platform Height | 45 ft in (13716 mm) |
| Max Horizontal Reach | 27 ft in (8229.6 mm) |
| Jib Range Of Motion - Vertical | 150 degrees |
| Platform Size | 2.6 ft in (792.48 mm) |
| Max Working Height | 51 ft in (15544.8 mm) |
| Jib Length | 4.3 ft in (1.32 m) |
Engine
| Engine Make | Kubota |
| Gross Power | 31 hp (23.2 kw) |
| System Voltage | 6 V |
| Number Of Batteries | 4 |
| Charger Amps | 260 amps |
Operational
| Leveling Capability | 12.5 degrees |
| Turntable Rotation | 350 degrees |
| Drive Speed | 4.8 mph (7.7 km/h) |
| Operating Weight | 5200 lb (2358.7 kg) |
| Tire Size | 26 x 12 Bar lug |
