Grove T40 2WD
Contents:
Dimensions
| Overall Length | 24.84 in (7570 mm) |
| Overall Width | 7.85 ft in (2390 mm) |
| Overall Height - Mast Lowered | 7.76 ft in (2364 mm) |
| Wheelbase | 8 ft in (2438 mm) |
| Ground Clearance | 10 in (254 mm) |
| Turning Radius | 15 ft in (4570 mm) |
Platform
| Max Platform Height | 39.38 ft in (12000 mm) |
| Max Horizontal Reach | 34.13 ft in (10400 mm) |
| Platform Inner Width | 35.83 in (910 mm) |
| Height Of Rails | 3.66 ft in (1115 mm) |
| Max Working Height | 45.94 ft in (14000 mm) |
| Max Platform Weight Capacity | 500.45 lb (227 kg) |
| Platform Inner Length | 93.71 in (2380 mm) |
Engine
| Engine Make | 2380 |
| Engine Model | LRG4.25 |
| Gross Power | 60 hp (44.8 kw) |
Operational
| Operating Weight | 12899.3 lb (5851 kg) |
| Fuel Capacity | 25.1 gal (95 L) |
| Hydraulic System Fluid Capacity | 24 gal (90.8 L) |
| Max Speed | 4 mph (6.5 km/h) |
| Tire Size | 12x16.5 Loader Lug |
| Tire Fill/Type | Pneumatic |
