Grove T66J 2WD
Contents:
Dimensions
| Overall Length | 34.13 in (10400 mm) |
| Overall Width | 8.5 ft in (2590 mm) |
| Overall Height - Mast Lowered | 8.08 ft in (2460 mm) |
| Wheelbase | 8.99 ft in (2740 mm) |
| Ground Clearance | 12 in (304.8 mm) |
| Turning Radius | 14.18 ft in (4320 mm) |
Platform
| Max Platform Height | 65.62 ft in (20000 mm) |
| Max Horizontal Reach | 54.79 ft in (16700 mm) |
| Platform Inner Length | 93.71 in (2380 mm) |
| Max Platform Weight Capacity | 500.45 lb (227 kg) |
| Max Working Height | 71.86 ft in (21900 mm) |
| Platform Inner Width | 35.83 in (910 mm) |
Engine
| Engine Make | 2380 |
| Engine Model | LRG4.25 |
| Gross Power | 60 hp (44.8 kw) |
Operational
| Operating Weight | 26700.2 lb (12111 kg) |
| Fuel Capacity | 25.1 gal (95 L) |
| Hydraulic System Fluid Capacity | 36.1 gal (136.3 L) |
| Max Speed | 4 mph (6.5 km/h) |
| Tire Size | 15x19.5 Loader Lug |
| Tire Fill/Type | Pneumatic |
