Case IH LLB 434XL ROTTER CUTTER
Contents:
Baler Pickup
| Number Of Tine Rows | 4 |
| Number Of Tines | 64 double (128) |
| Outer Tine-To-Tine Width | 86.62 in (2200 mm) |
| Pickup Working Width | 92.6 in (2352 mm) |
| Tine Spacing | 2.6 in (66 mm) |
| Gauge Wheels | Two 15x6.00-6 4PR,caster opt. |
| Number Of Tine Bars | 4 |
Dimensions
| Tractor Pto Power Required | 159.59 hp (119 kw) |
| Baler Width Min | 109.53 in (2782 mm) |
| Height Tandem Axle | 126.89 in (3223 mm) |
| Height, Single Axle | 126.89 in (3223 mm) |
| Length With Bale Chute Folded | 327.37 in (8315 mm) |
| Baler Width Max | 117.49 in (2984 mm) |
Knotters
| Knotters Type | Double knot |
| Number Of Knotters | 6 |
| Twine Ball Storage Quantity | 32 |
Maindrive
| Main Drive Protection | Shearbolt, overrunning clutch & slip clutch |
Sales Literature
| Literature Number | News release |
| Literature Date | September, 2016 |
Years Of Manufacture
| Manufacturing Status | Current |
| First Entry Date | September, 2016 |
Engine
| Pto Speed | 1000 rpm |
| Number Of Remote Hydraulic Valves | 3 |
Bale Size
| Bale Height | 35.5 in (900 mm) |
| Bale Width | 47.3 in (1200 mm) |
| Bale Length - Max | 118.2 in (3000 mm) |
Feeding
| Feeder Description | Rotor, 47.2\" (1200 mm), \"W\" tine |
| Stuffer Description | Fork,6 tines |
Tires
| Tire Size Single Axle | WH600/55-22.5 or 700/40-22.5 |
Weights
| Weight Single Axle | 20062.1 lb (9100 kg) |
| Weight Tandem Axle | 21384.9 lb (9700 kg) |
Tires
| Tire Size Tandem Axle | WH500/50-17.0 or 550/45 R22.5 |
Plunger
| Density Control | AFS Pro 300 or AFS Pro 700 |
| Plunger Speed (Strokes/Min) | 48 |
| Plunger Stroke | 28 in (710 mm) |
Wrapping System
| Cutter Knives | 15 or 29 knives,hydraulic activation |
