Terex AC55L
Browse All Terex or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 32.49 ft in (9.9 m) |
| Max Height @ Max Raise Angle - No Jib | 144.36 ft in (44 m) |
| Min Working Radius | 8.54 ft in (2.6 m) |
| Max Working Radius | 98.43 ft in (30 m) |
| Max Elevating Angle | 80 degrees |
| Number Of Sections | 6 |
| Max Lift Capacity | 121254.24 lb (55000 kg) |
| Swing Speed | 1.8 rpm |
Dimensions
| Transport Length | 36.88 ft in (11240 mm) |
| Transport Width | 7.39 ft in (2250 mm) |
| Transport Height | 12.8 ft in (3900 mm) |
| Width W/ Outriggers Extended | 20.67 ft in (6300 mm) |
| Carrier Length | 32.39 ft in (9870 mm) |
| Upper Structure Tail Swing Radius | 25.1 ft in (7650 mm) |
Carrier Engine
| Make | Terex |
| Model | OM 501 LA |
| Gross Power | 353 hp (263.3 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 1276 lb ft (1730 Nm) |
| Torque Measured @ | 1080 rpm |
Operational
| Number Of Axels | 3 |
| Carrier Fuel Capacity | 105.7 gal (400 L) |
| Upper Structure Hydraulic System Fluid Capacity | 154.6 gal (585 L) |
| Operating Voltage | 24 V |
| Tire Size | 16.00 R 25 |
Transmission
| Transmission Type | Automated Gearbox |
| Number Of Forward Gears | 12 |
