Terex AC435
Browse All Terex or All Terrain Crane Models
Contents:
Boom
| Number Of Sections | 4 |
Dimensions
| Transport Length | 50.15 ft in (15285 mm) |
| Transport Width | 9.85 ft in (3000 mm) |
| Transport Height | 12.96 ft in (3950 mm) |
| Width W/ Outriggers Extended | 24.61 ft in (7500 mm) |
| Carrier Length | 41.46 ft in (12635 mm) |
| Upper Structure Tail Swing Radius | 16.41 ft in (5000 mm) |
Upper Structure Engine
| Make | Terex |
| Model | OM 366 A |
| Gross Power | 162.3 hp (121 kw) |
| Power Measured @ | 2300 rpm |
| Max Torque | 413.1 lb ft (560 Nm) |
| Torque Measured @ | 1400 rpm |
Carrier Engine
| Make | Terex |
| Model | OM 442 LA |
| Gross Power | 429.2 hp (320 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 1327.7 lb ft (1800 Nm) |
| Torque Measured @ | 1600 rpm |
Operational
| Number Of Axels | 5 |
| Upper Structure Fuel Capacity | 74 gal (280 L) |
| Carrier Fuel Capacity | 132.1 gal (500 L) |
| Operating Voltage | 24 V |
| Tire Size | 16.00 R 25 |
Transmission
| Transmission Type | ZF-Transmatik |
| Number Of Forward Gears | 16 |
| Number Of Reverse Gears | 2 |
