Kato KA900
Browse All Kato or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 49.22 ft in (15 m) |
| Max Height @ Max Raise Angle - No Jib | 157.49 ft in (48 m) |
| Min Working Radius | 9.19 ft in (2.8 m) |
| Max Working Radius | 137.8 ft in (42 m) |
| Max Elevating Angle | 83 degrees |
| Max Lift Capacity | 198416.05 lb (90000 kg) |
| Swing Speed | 1.95 rpm |
| Number Of Sections | 5 |
Dimensions
| Transport Length | 43.48 ft in (13250 mm) |
| Transport Width | 9.03 ft in (2750 mm) |
| Transport Height | 12.9 ft in (3930 mm) |
| Ground Clearance | 0.99 ft in (300 mm) |
| Width W/ Outriggers Extended | 24.28 ft in (7400 mm) |
| Carrier Length | 37.5 ft in (11430 mm) |
| Upper Structure Tail Swing Radius | 12.37 ft in (3770 mm) |
Upper Structure Engine
| Make | Kato |
| Model | Penta TD730VE |
| Gross Power | 201.2 hp (150 kw) |
| Power Measured @ | 2250 rpm |
| Max Torque | 590.1 lb ft (800 Nm) |
| Torque Measured @ | 1450 rpm |
| Displacement | 410.7 cu in (6.8 L) |
Carrier Engine
| Make | Kato |
| Model | D12A 420 (EURO2) |
| Gross Power | 414.4 hp (309 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 1364.5 lb ft (1850 Nm) |
| Torque Measured @ | 1200 rpm |
| Displacement | 740.3 cu in (12.2 L) |
Operational
| Operating Weight | 105821.9 lb (48000 kg) |
| Number Of Axels | 4 |
| Upper Structure Fuel Capacity | 66.1 gal (250 L) |
| Carrier Fuel Capacity | 105.7 gal (400 L) |
| Upper Structure Hydraulic System Fluid Capacity | 224.6 gal (850 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
| Tire Size | 445/95 R25 177E ROAD |
Transmission
| Transmission Type | full automatic |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 1 |
| Max Speed - Forward | 46.7 mph (75 km/h) |
