Grove GMK5165
Browse All Grove or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 42 ft in (12.81 m) |
| Max Height @ Max Raise Angle - No Jib | 197 ft in (60.05 m) |
| Min Working Radius | 8 ft in (2.44 m) |
| Max Working Radius | 180 ft in (54.87 m) |
| Max Elevating Angle | 83 degrees |
| Number Of Sections | 6 |
| Max Lift Capacity | 215000 lb (97522.37 kg) |
| Swing Speed | 1.7 rpm |
Dimensions
| Transport Length | 49.45 ft in (15070 mm) |
| Transport Width | 9.03 ft in (2750 mm) |
| Transport Height | 12.83 ft in (3910 mm) |
| Width W/ Outriggers Extended | 24.61 ft in (7500 mm) |
| Carrier Length | 47.81 ft in (14570 mm) |
| Upper Structure Tail Swing Radius | 14.57 ft in (4438 mm) |
Upper Structure Engine
| Number Of Cylinders | 4 |
| Make | Grove |
| Model | OM 904 LA |
| Gross Power | 174.4 hp (130 kw) |
| Power Measured @ | 2200 rpm |
| Max Torque | 497.9 lb ft (675 Nm) |
| Torque Measured @ | 100 rpm |
Carrier Engine
| Make | Grove |
| Model | OM 502 LA |
| Gross Power | 509.6 hp (380 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 1770.2 lb ft (2400 Nm) |
| Torque Measured @ | 1200 rpm |
| Number Of Cylinders | 8 |
Operational
| Operating Weight | 109944.6 lb (49870 kg) |
| Number Of Axels | 5 |
| Carrier Fuel Capacity | 105.7 gal (400 L) |
| Upper Structure Hydraulic System Fluid Capacity | 211.4 gal (800 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
| Tire Size | 20.5R25 |
Transmission
| Transmission Type | Daimler Chrysler G240-16 |
| Number Of Forward Gears | 16 |
| Max Speed - Forward | 52.9 mph (85 km/h) |
