Grove GMK5120B
Browse All Grove or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 42 ft in (12.81 m) |
| Max Height @ Max Raise Angle - No Jib | 167 ft in (50.91 m) |
| Min Working Radius | 8 ft in (2.44 m) |
| Max Working Radius | 150 ft in (45.72 m) |
| Max Elevating Angle | 83 degrees |
| Number Of Sections | 5 |
| Max Lift Capacity | 240000 lb (108862.18 kg) |
| Swing Speed | 1.7 rpm |
Dimensions
| Transport Length | 47.47 ft in (14468 mm) |
| Transport Width | 10.08 ft in (3070 mm) |
| Transport Height | 12.83 ft in (3910 mm) |
| Width W/ Outriggers Extended | 24.61 ft in (7500 mm) |
| Carrier Length | 39.18 ft in (11940 mm) |
| Upper Structure Tail Swing Radius | 13.85 ft in (4220 mm) |
Upper Structure Engine
| Make | Grove |
| Model | OM904LA |
| Gross Power | 167.7 hp (125 kw) |
| Power Measured @ | 2300 rpm |
| Max Torque | 486.8 lb ft (660 Nm) |
| Torque Measured @ | 1200 rpm |
Carrier Engine
| Make | Grove |
| Model | OM502LA |
| Gross Power | 469.4 hp (350 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 1696.4 lb ft (2300 Nm) |
| Torque Measured @ | 1080 rpm |
Operational
| Operating Weight | 120988 lb (54879.3 kg) |
| Number Of Axels | 5 |
| Upper Structure Fuel Capacity | 52.9 gal (200 L) |
| Carrier Fuel Capacity | 105.7 gal (400 L) |
| Upper Structure Hydraulic System Fluid Capacity | 222 gal (840 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 amps |
| Tire Size | 20.5R25 |
Transmission
| Transmission Type | Daimler Chrysler G240-16 |
| Number Of Forward Gears | 16 |
| Number Of Reverse Gears | 2 |
| Max Speed - Forward | 52.9 mph (85 km/h) |
