Grove GMK4085B
Browse All Grove or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 38 ft in (11.59 m) |
| Max Height @ Max Raise Angle - No Jib | 125 ft in (38.1 m) |
| Min Working Radius | 10 ft in (3.05 m) |
| Max Working Radius | 110 ft in (33.53 m) |
| Max Elevating Angle | 84 degrees |
| Number Of Sections | 4 |
| Max Lift Capacity | 162000 lb (73481.97 kg) |
| Swing Speed | 2.4 rpm |
Dimensions
| Transport Length | 43.25 ft in (13180 mm) |
| Transport Width | 9.39 ft in (2860 mm) |
| Transport Height | 12.16 ft in (3705 mm) |
| Width W/ Outriggers Extended | 23.63 ft in (7200 mm) |
| Carrier Length | 33.14 ft in (10100 mm) |
| Upper Structure Tail Swing Radius | 11.49 ft in (3500 mm) |
Carrier Engine
| Make | Grove |
| Model | OM 442A |
| Gross Power | 335.3 hp (250 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 1106.4 lb ft (1500 Nm) |
| Torque Measured @ | 1200 rpm |
Operational
| Operating Weight | 89630 lb (40655.5 kg) |
| Number Of Axels | 4 |
| Carrier Fuel Capacity | 132.1 gal (500 L) |
| Upper Structure Hydraulic System Fluid Capacity | 237.8 gal (900 L) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 amps |
| Tire Size | 20.5R25 |
Transmission
| Transmission Type | automatic powershift |
| Number Of Forward Gears | 5 |
| Number Of Reverse Gears | 1 |
| Max Speed - Forward | 46 mph (74 km/h) |
