Grove AT9120
Browse All Grove or All Terrain Crane Models
Contents:
Boom
| Min Height @ Max Raise Angle | 42.5 ft in (12.96 m) |
| Max Height @ Max Raise Angle - No Jib | 160 ft in (48.77 m) |
| Min Working Radius | 10 ft in (3.05 m) |
| Max Working Radius | 140 ft in (42.68 m) |
| Max Elevating Angle | 80 degrees |
| Max Lift Capacity | 240000 lb (108862.18 kg) |
| Swing Speed | 1.4 rpm |
| Number Of Sections | 5 |
Dimensions
| Transport Length | 50.86 ft in (15501 mm) |
| Transport Width | 9.52 ft in (2900 mm) |
| Transport Height | 13.1 ft in (3990 mm) |
| Ground Clearance | 0.92 ft in (280 mm) |
| Width W/ Outriggers Extended | 25.07 ft in (7640 mm) |
| Carrier Length | 40.82 ft in (12439 mm) |
| Upper Structure Tail Swing Radius | 14.58 ft in (4442 mm) |
Upper Structure Engine
| Make | Grove |
| Model | OM366LA |
| Gross Power | 207.9 hp (155 kw) |
| Power Measured @ | 2600 rpm |
| Max Torque | 472.1 lb ft (640 Nm) |
| Torque Measured @ | 1500 rpm |
| Displacement | 366.2 cu in (6 L) |
Carrier Engine
| Make | Grove |
| Model | OM442LA |
| Gross Power | 429.2 hp (320 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 1327.7 lb ft (1800 Nm) |
| Torque Measured @ | 1600 rpm |
| Displacement | 891 cu in (14.6 L) |
Operational
| Operating Weight | 157000 lb (71214 kg) |
| Number Of Axels | 5 |
| Carrier Fuel Capacity | 114.2 gal (432 L) |
| Upper Structure Hydraulic System Fluid Capacity | 290.6 gal (1100 L) |
| Operating Voltage | 24 V |
| Tire Size | 20.5R25 |
Transmission
| Transmission Type | fully automatic |
| Number Of Forward Gears | 5 |
| Number Of Reverse Gears | 1 |
| Max Speed - Forward | 43.5 mph (70 km/h) |
