Morris Maxim II 29'
Contents:
Frame Widths
| Transport Length | 25.66 ft in (7.82 m) |
| Transport Width | 19.79 ft in (6.03 m) |
| Transport Height | 12.08 ft in (3.68 m) |
| Inner Wing | 7.52 ft in (2.29 m) |
| Main Frame | 14.51 ft in (4.42 m) |
Base Size
| Base Width | 29 ft in (8.9 m) |
| Number Of Ranks | 4 |
| Rank To Rank Spacing | 24.1 in (61 cm) |
| Frame Depth | 76 in (193.1 cm) |
Working Width
| 7.2 In Spacing | 29.5 ft in (9 m) |
| 10 In Spacing | 30 ft in (9.2 m) |
| 12 In Spacing | 29.1 ft in (8.9 m) |
Number Of Shanks
| 7.2 In Spacing | 47 |
| 10 In Spacing | 36 |
| 12 In Spacing | 29 |
Weights
| 7.2 In Spacing | 14993.7 lb (6801 kg) |
| 10 In Spacing | 13593.8 lb (6166 kg) |
| 12 In Spacing | 12357 lb (5605 kg) |
Tires
| Main Frame Casters | (2) 9.5Lx15 FI Load range D |
| Inner Wing Casters | (2) 11Lx15 |
| Rear Transport Wheels | (4) 11Lx15 FI load range D 6 bolt hub |
