Case IH FLEX HOE 700
Contents:
Dimensions
| Basic Weight, Maximum | 36499.73 lb (16556 kg) |
| Basic Weight, Minimum | 31100.61 lb (14107 kg) |
| Number Of Furrows, Maximum | 96 |
| Number Of Furrows, Minimum | 60 |
| Transport Height- Maximum | 13.46 ft in (4.1 m) |
| Transport Height- Minimum | 13.46 ft in (4.1 m) |
| Transport Width- Maximum | 17.72 ft in (5.4 m) |
| Transport Width-Minimum | 17.72 ft in (5.4 m) |
| Variants Available | 3 widths, 3 row spacings |
| Working Width- Maximum, | 80.06 ft in (24.4 m) |
| Working Width- Minimum | 60.04 ft in (18.3 m) |
Primary Opener Assembly
| Opener Type | Conventional C-shank standard; Edge-on optional. |
Configuration
| Seeding Method | Conventional Till hoe |
Primary Opener Assembly
| Depth Gauging System | Single-point |
Tires And Frame
| Center Frame Tire | 11L x 15FI up to 12.5L x 15FI dual |
Configuration
| Row Spacings | 7.5 (191) for 60 only 10, 12 (254, 305) |
| Seed Supply | Air Cart, between or behind |
Tires And Frame
| Wing Frame Tire | 11L x 15FI up to 12.5L x 15FI dual |
Configuration
| Frame Sections | 5 section |
Tires And Frame
| Number Of Ranks | 4 |
Configuration
| Transport Folding Method | Horizontal rear fold |
Tires And Frame
| Distance Between Ranks | 26 in (660 mm) |
Primary Opener Assembly
| Type Of Fertilizer Delivery | Single or double shoot |
Engine
| Engine Make | Case IH |
| Engine Model | Flex Hoe 700 |
Wheels
| Press Wheels Mounted On Opener Or To Frame | In-line rear gangs, separate by wing section |
| Press Wheel Description | Steel Wheel or rubber tire, 3 to 5.5 |
