YTO ZL30
Browse All YTO or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.13 ft in (2780 mm) |
| Bucket Capacity - Heaped | 1.97 yd3 (1.5 m3) |
Dimensions
| Length With Bucket On Ground | 22.31 ft in (6800 mm) |
| Width Over Tires | 7.94 ft in (2420 mm) |
| Height To Top Of Cab | 10.18 ft in (3100 mm) |
Engine
| Engine Model | LR6108G6F |
| Gross Power | 123.4 hp (92 kw) |
Operational
| Operating Weight | 21605.4 lb (9800 kg) |
| Fuel Capacity | 39.7 gal (150 L) |
| Hydraulic System Fluid Capacity | 34.4 gal (130 L) |
| Static Tipping Weight | 6613.9 lb (3000 kg) |
| Turning Radius | 18.8 ft in (5725 mm) |
Transmission
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 19.9 mph (32 km/h) |
| Max Speed - Reverse | 22.4 mph (36 km/h) |
Hydraulic System
| Raise Time | 7.5 sec |
