Volvo L45
Browse All Volvo or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.13 ft in (2780 mm) |
| Bucket Capacity - Heaped | 2.1 yd3 (1.6 m3) |
| Bucket Width | 7.39 ft in (2250 mm) |
| Breakout Force | _ - (63 kN) |
Dimensions
| Ground Clearance | 1.38 ft in (420 mm) |
| Length With Bucket On Ground | 19.72 ft in (6010 mm) |
| Width Over Tires | 7.11 ft in (2165 mm) |
| Height To Top Of Cab | 9.68 ft in (2950 mm) |
| Wheelbase | 8.04 ft in (2450 mm) |
| Hinge Pin - Max Height | 11.98 ft in (3650 mm) |
| Reach At Max Lift And Dump | 2.81 ft in (855 mm) |
Engine
| Number Of Cylinders | 4 |
| Engine Make | 2349 |
| Engine Model | BF4M 1013 |
| Net Power | 99 hp (73.9 kw) |
| Gross Power | 107 hp (79.8 kw) |
| Power Measured @ | 2100 rpm |
| Max Torque | 309.8 lb ft (420 Nm) |
| Displacement | 290.5 cu in (4.8 L) |
| Torque Measured @ | 1400 rpm |
| Aspiration | turbocharged |
Operational
| Operating Weight | 17482.7 lb (7930 kg) |
| Fuel Capacity | 34.4 gal (130 L) |
| Hydraulic System Fluid Capacity | 29.1 gal (110 L) |
| Engine Oil Fluid Capacity | 3.2 gal (12 L) |
| Front Axle/Diff Fluid Capacity | 2.1 gal (7.9 L) |
| Rear Axle/Diff Fluid Capacity | 2.7 gal (9.9 L) |
| Static Tipping Weight | 12345.9 lb (5600 kg) |
| Turning Radius | 16 ft in (4875 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 amps |
| Rear Axle Oscillation | 20 degrees |
| Tire Size | 15.5-25 |
Transmission
| Number Of Forward Gears | 3 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 21.8 mph (35 km/h) |
| Max Speed - Reverse | 10 mph (16 km/h) |
Hydraulic System
| Relief Valve Setting | 3626 psi (25000 kPa) |
| Pump Flow Capacity | 28.1 gal/min (106 L/min) |
| Raise Time | 6 sec |
| Dump Time | 1.5 sec |
| Lower Time | 5 sec |
