Volvo BM LM218
Browse All Volvo BM or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 10.11 ft in (3080 mm) |
| Breakout Force | 584503.21 lb (2600 kN) |
| Bucket Capacity - Heaped | 2.75 yd3 (2.1 m3) |
| Bucket Capacity - Struck | 0.79 yd3 (0.6 m3) |
Dimensions
| Ground Clearance | 1.15 ft in (350 mm) |
| Length With Bucket On Ground | 16.82 ft in (5125 mm) |
| Height To Top Of Cab | 8.34 ft in (2540 mm) |
| Wheelbase | 7.55 ft in (2300 mm) |
Engine
| Number Of Cylinders | 3 |
| Engine Model | BM 1113 |
| Net Power | 56 hp (41.8 kw) |
| Gross Power | 63 hp (47 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 182 lb ft (246.8 Nm) |
| Displacement | 230.7 cu in (3.8 L) |
| Torque Measured @ | 1100 rpm |
Operational
| Operating Weight | 12600 lb (5715.3 kg) |
| Static Tipping Weight | 5291.1 lb (2400 kg) |
| Turning Radius | 16.5 ft in (5000 mm) |
| Operating Voltage | 12 V |
| Tire Size | front 16.9-30/10 rear 9-20/10 |
Transmission
| Number Of Forward Gears | 5 |
| Number Of Reverse Gears | 5 |
| Max Speed - Forward | 16.2 mph (26 km/h) |
| Max Speed - Reverse | 12.5 mph (20 km/h) |
Hydraulic System
| Relief Valve Setting | 1070 psi (7377.4 kPa) |
| Pump Flow Capacity | 34.4 gal/min (130 L/min) |
