Terex TL510
Browse All Terex or Wheel Loader Models
Contents:
Bucket
| Bucket Capacity - Heaped | 6.68 yd3 (5.1 m3) |
| Breakout Force | _ - (252 kN) |
Dimensions
| Ground Clearance | 1.71 ft in (520 mm) |
| Length With Bucket On Ground | 305.12 ft in (93000 mm) |
| Height To Top Of Cab | 11.98 ft in (3650 mm) |
| Wheelbase | 12.41 ft in (3780 mm) |
| Reach At Max Lift And Dump | 4.27 ft in (1300 mm) |
Engine
| Engine Make | 2347 |
| Engine Model | QSM11 |
| Net Power | 364.8 hp (272 kw) |
Operational
| Operating Weight | 65036.4 lb (29500 kg) |
| Fuel Capacity | 129.5 gal (490 L) |
| Static Tipping Weight | 45635.7 lb (20700 kg) |
| Tire Size | 29.5R25 |
