Caterpillar 950F
Browse All Caterpillar or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 9.65 ft in (2941 mm) |
| Bucket Capacity - Heaped | 3.8 yd3 (2.9 m3) |
| Bucket Capacity - Struck | 3.31 yd3 (2.53 m3) |
| Bucket Width | 9.23 ft in (2811 mm) |
| Breakout Force | 35801 lb (159.26 kN) |
Dimensions
| Ground Clearance | 1.56 ft in (474 mm) |
| Length With Bucket On Ground | 25.23 ft in (7689 mm) |
| Width Over Tires | 9.04 ft in (2753 mm) |
| Height To Top Of Cab | 11.55 ft in (3520 mm) |
| Wheelbase | 10.44 ft in (3180 mm) |
| Hinge Pin - Max Height | 12.97 ft in (3953 mm) |
| Reach At Max Lift And Dump | 3.62 ft in (1103 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2236 |
| Engine Model | 3116 |
| Net Power | 170 hp (126.8 kw) |
| Gross Power | 180 hp (134.3 kw) |
| Power Measured @ | 2200 rpm |
| Displacement | 402.8 cu in (6.6 L) |
| Aspiration | Turbocharged |
Operational
| Operating Weight | 34678.8 lb (15730 kg) |
| Fuel Capacity | 58.7 gal (222 L) |
| Hydraulic System Fluid Capacity | 40.5 gal (153 L) |
| Engine Oil Fluid Capacity | 5.3 gal (20 L) |
| Cooling System Fluid Capacity | 13 gal (49 L) |
| Transmission Fluid Capacity | 9 gal (34 L) |
| Front Axle/Diff Fluid Capacity | 9.6 gal (36 L) |
| Rear Axle/Diff Fluid Capacity | 9.6 gal (36 L) |
| Static Tipping Weight | 23243.4 lb (10543 kg) |
| Turning Radius | 21.1 ft in (6419 mm) |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 50 amps |
| Rear Axle Oscillation | 26 degrees |
| Tire Size | 23.5-25 12PR |
Transmission
| Transmission Type | Planetary powershift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 4 |
| Max Speed - Forward | 24.4 mph (39.3 km/h) |
| Max Speed - Reverse | 26.7 mph (43 km/h) |
Hydraulic System
| Relief Valve Setting | 3000 psi (20684.3 kPa) |
| Pump Flow Capacity | 62.7 gal/min (237 L/min) |
| Raise Time | 6.6 sec |
| Dump Time | 2.2 sec |
| Lower Time | 3 sec |
