Case 1021FXR
Browse All Case or Wheel Loader Models
Contents:
Bucket
| Dump Clearance At Max Raise | 12.25 ft in (3733 mm) |
| Bucket Capacity - Struck | 4.07 yd3 (3.12 m3) |
| Bucket Width | 10.49 ft in (3195 mm) |
| Bucket Capacity - Heaped | 4.75 yd3 (3.64 m3) |
Dimensions
| Ground Clearance | 1.67 ft in (509 mm) |
| Length With Bucket On Ground | 30.43 ft in (9274 mm) |
| Width Over Tires | 9.81 ft in (2990 mm) |
| Height To Top Of Cab | 11.73 ft in (3573 mm) |
| Wheelbase | 11.65 ft in (3550 mm) |
| Hinge Pin - Max Height | 15.84 ft in (4825 mm) |
| Reach At Max Lift And Dump | 3.9 ft in (1187 mm) |
Engine
| Number Of Cylinders | 6 |
| Engine Make | 2239 |
| Engine Model | F2CFE614C |
| Net Power | 296 hp (220.8 kw) |
| Gross Power | 320 hp (238.7 kw) |
| Power Measured @ | 1800 rpm |
| Max Torque | 1091 lb ft (1479.2 Nm) |
| Displacement | 531 cu in (8.8 L) |
| Torque Measured @ | 1200 rpm |
| Aspiration | Turbocharged |
| Torque Rise | 49 % |
Operational
| Operating Weight | 56452 lb (25606.2 kg) |
| Fuel Capacity | 125 gal (473.2 L) |
| Hydraulic System Fluid Capacity | 66 gal (249.9 L) |
| Engine Oil Fluid Capacity | 8.1 gal (30.3 L) |
| Cooling System Fluid Capacity | 15 gal (56.8 L) |
| Transmission Fluid Capacity | 12 gal (45.4 L) |
| Front Axle/Diff Fluid Capacity | 13.5 gal (51.1 L) |
| Rear Axle/Diff Fluid Capacity | 13.5 gal (51.1 L) |
| Static Tipping Weight | 35504 lb (16104.4 kg) |
| Turning Radius | 24 ft in (7306 mm) |
| Tire Size | 26.5R25 |
Transmission
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 3 |
| Max Speed - Forward | 23.2 mph (37.4 km/h) |
| Max Speed - Reverse | 16.1 mph (26 km/h) |
Hydraulic System
| Pump Flow Capacity | 93 gal/min (352.1 L/min) |
| Raise Time | 6.2 sec |
| Dump Time | 1.3 sec |
| Lower Time | 2.6 sec |
