Volvo SD75B Smooth
Browse All Volvo or Vibratory Smooth Drum Roller Models
Contents:
Dimensions
| Overall Length | 198.59 in (5044 mm) |
| Overall Width | 5.5 ft in (1676 mm) |
| Height To Top Of Cab | 9.6 ft in (2924 mm) |
| Wheelbase | 105.4 in (2677 mm) |
| Ground Clearance | 15.08 in (383 mm) |
Speeds
| High | 7.7 mph (12.3 km/h) |
| Low | 4.1 mph (6.5 km/h) |
Electrical System
| Voltage | 12 V |
| Batteries | 1 x 1125 |
| Alternator | 100 |
Propulsion
| Propulsion Type | Hydrostatic |
| Tyre | 14.9-24 R3 6PR TT |
Vibration
| Centrifugal Force High Amp | 31248.5 lb (139 kN) |
Propulsion
| Drum Drive | LSHT Motor |
Vibration
| Centrifugal Force Low Amp | 27201.9 lb (121 kN) |
| Nominal Amplitude High Amp | 0.1 in (2 mm) |
| Nominal Amplitude Low Amp | 0.1 in (1.5 mm) |
Engine
| Rated Horsepower | 74.3 hp (55.4 kw) |
| Engine Make | Volvo |
| Engine Model | D3.8 Tier 4 F |
| Engine | Turbocharged 4 cylinder |
Operational
| Operating Weight | 15855.7 lb (7192 kg) |
| Shipping Weight - Empty | 15611 lb (7081 kg) |
| Fuel Capacity | 30.4 gal (115 L) |
| Hydraulic System Fluid Capacity | 15.9 gal (60 L) |
| Inside Turning Radius | 128 in (3249 mm) |
Drum
| Drum Width | 66 in (1676.4 mm) |
| Drum Diameter | 48 in (1219.2 mm) |
| Shell Thickness | 1 in (25.4 mm) |
Brakes
| Parking Brake | Spring-applied, hydraulically released on drum & axle |
| Service Brake | Hydrostatic |
