Vibromax 1405D
Contents:
| Overall Length | 18.67 in (5690 mm) |
| Height To Top Of Cab | 10.68 ft in (3255 mm) |
| Wheelbase | 9.73 in (2965 mm) |
| Ground Clearance | 18.12 in (460 mm) |
| Engine Make | 2347 |
| Engine Model | 6BT5.9C |
| Gross Power | 185.1 hp (138 kw) |
| Power Measured @ | 2300 rpm |
| Displacement | 359 cu in (5.9 L) |
| Aspiration | turbocharged |
| Operating Weight | 31305.7 lb (14200 kg) |
| Fuel Capacity | 104.9 gal (397 L) |
| Max Speed | 7.1 mph (11.4 km/h) |
| Tires *If Applicable | 23.1x20-26 8PR |
| Drum Width | 82.7 in (2100 mm) |
| Drum Diameter | 59.1 in (1500 mm) |
| Static Linear Load | 206 lb/in (36.8 kg/cm) |
| Vibration Frequency 1 | 29 Hz |
| Nominal Amplitude - Med | 0.1 in (1.5 mm) |
| Vibration Frequency 2 | 35 Hz |
| Centrifugal Force - Med | 38667.2 lb (172 kN) |
